ICMI Product
Square Frame & Cover without Hinges - with Bolts

IC-G2-D-31000

Use for footways, pedestrian and comparable areas, car parks or car parking decks.

Standard
EN 124-2
Material
GGG
Load
B125
Status
Available
Product Preview
IC-G2-D-31000
ParkingB125
IC-G2-D-31000
Double Seal
With high security Lock
Home>Double Seal Covers>B125>IC-G2-D-31000

Certification & Specifications

Tested & certified for B125 (b125 Ton) according to EN 124-2
Coating
Applied coat according to BS 3416 Epoxy Paint, Or any other type of paint according to the customer’s requirements.
Marking
All manhole covers are marked with the following: (Name of Manufacturer - EN124 Class Load and Material)

Main Data & Applications

Standard
EN 124-2
Material
GGG
B125
Load Class
B125
Double Seal
Seal Type
Double Seal
With high security Lock
Lock Type
high security Lock
Parking Areas
Application
Parking Areas
Pattern & Design
Design of cover pattern allows for special Logo or project design to be inserted in its specified area on the cover. • Square frame base design. • Square cover design with non slip pattern, Lock and bolts, double seal.
Technical Specifications
Art. No.Over baseClear OpenHeight
IC-G2-D-31001500x500400x40042
IC-G2-D-31002740x740600x60042
IC-G2-D-31003995x995800x80042
Download Datasheet PDF
