| Art. No. | Part | Name | Material |
|---|---|---|---|
| IC-D-91001 | 1 | Surface box | Ductile Iron |
| 2 | Cap | Ductile Iron | |
| 3 | Cap top / Dust cover | Plastic | |
| 4 | Stem | Steel Sq. Sec. with variable length 600 - 800 -1000 - 1500 mm | |
| 5 | Pipe 3 inch Dia. | Plastic | |
| 6 | Knob | Ductile Iron | |
| 7 | Protect Cover | Ductile Iron | |
| 8 | Cap screw tool | Steel Rod & Ductile iron cap screw with length of 80 mm |
SURFACE BOX ASSEMBLE
Mechanism
Standard:
EN124-2:2015
Material:
EN 1563 – Grad GJS-500/7
Features
Applied Bitumen coat according to BS 3416 or Epoxy Paint.
All manhole covers are marked with the following:
(Name of Manufacturer – En124 Class Load and Material)
